Custom Series

Sapphire NITRO

Engine Clock

Boost Clock: Up to 2622 MHz/Game Clock: Up to 2548 MHz
Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual/individual game clock results may vary.

Stream Processors

2560

Infinity Cache

96MB

Ray Accelerators

40

Memory Size/Bus

12GB GDDR6

Displays

Maximum 4 Displays

Resolution

HDMI™: 7680×4320/DisplayPort1.4: 7680×4320

Interface

PCI-Express 4.0

Output

1x HDMI /3x DisplayPort

BIOS Support

Dual UEFI

Game Index

4K

Sapphire Features

Dual BIOS/TriXX Software BIOS Switch/Premium Digital Power Design/Fuse Protection
Tri-X Cooling Technology/Intelligent Fan Control/Precision Fan Control/Backplate with ARGB/Two-Ball Bearing Fans/Hybrid Fan Blade/Wave Fin Design/V Shape Fin Design for GPU Cooling/Integrated Cooling Module/TriXX Supported/Fan Check/Fan Quick Connect/TriXX Boost/NITRO Glow/External RGB LED MB Synchronization

AMD Features

AMD RDNA™ 2 Gaming Architecture/DirectX® 12 Ultimate
Hardware Raytracing /Smart Access Memory/Infinity Cache/7nm GPU
PCI® Express 4.0 Support/AMD FreeSync™ Technology
DisplayPort™ 1.4 with DSC /HDMI™ 2.1 VRR/Video Streaming up to 8K/Radeon™ VR Ready Premium /AMD FidelityFX/Radeon™ Image Sharpening
Radeon™ Anti-Lag/Radeon™ Software/Game Driver Optimizations

Cooling

3 Fans

Form Factor

2.5 slot, ATX/Dimension: 310.05(L)X 130.75(W)X 51.4 (H)mm

Power Consumption

260W (Board Power)

OS

Linux®, Windows® 7*, Windows® 10, and Windows 8.1. 64-bit operating system required/*Does not support all features including but not limited to Hardware Raytracing

System Requirement

Minimum 650 Watt Power Supply/1 x 8-pin + 1 x 6-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard./Minimum 8GB of system memory. 16GB recommended.
